JTHH风电款环链电动葫芦

JTHH Wind Power Electric Chain Hoist
Jentan Code		W.L.L(t)	Lifting Speed (m/min)	Hook Dostance (mm)	Power (kw)	Duty Circle (%)	Chain Size (mm)	N.W. (kg)	Extra Weight Per Lift (kg)	Dimensions(mm)
Jentan Code		W.L.L(t)	Lifting Speed (m/min)	Hook Dostance (mm)	Power (kw)	Duty Circle (%)	Chain Size (mm)	N.W. (kg)	Extra Weight Per Lift (kg)	A	B	C	D	E	F	G	H	L	K	M	N
Dual Speed	JTHH2J1-0.25AF	0.25	5.3/16	439	0.3/0.9	30	5X15	33	0.56	439	428	229	165	124	235	92	168	35	41	23	27
	JTHH2L1-0.32AF	0.32	8/24	439	0.53/1.6	30	5X15	40	0.56	439	483	229	165	124	235	92	168	35	41	23	27
	JTHH2L1-0.35AF	0.35	8/24	439	0.53/1.6	30	5X15	40	0.56	439	483	229	165	124	235	92	168	35	41	23	27
	JTHH2G1-0.5AF	0.5	3.3/10	439	0.53/1.6	40	6.3X19	38	0.86	450	458	229	165	124	235	92	168	40	45	27	30
	JTHH2G1-0.6AF	0.6	3.3/10	455	0.53/1.6	30	6.3X19	38	0.88	450	458	229	165	124	235	92	168	40	45	27	30
	JTHH2G1-0.75BF	0.75	3.3/10	545	0.53/1.6	30	7X21	59	1.09	540	493	294	193	171	247	114	197	45	49	31	36
	JTHH2G1-0.8BF	0.8	3.3/10	545	0.53/1.6	30	7X21	59	1.09	540	493	294	193	171	247	114	197	45	49	31	36
