EWF-40弹簧平衡器
| 弹簧平衡器 | |||||||
| Model | Capacity(kg) | Travel (m) | Cable diameter(Фmm) | N.W (kg) | piece/canton | The inside box's size (mm) | The outer canton's size (mm) |
| JTPH-A-3 | 1-3 | 1.5 | 3.2 | 1.5 | 5 | 220*180*75 | 405*235*205 |
| JTPH-A-5 | 3-5 | 1.5 | 3.2 | 1.5 | 5 | 220*180*75 | 405*235*205 |
| JTPH-A-9 | 5-9 | 1.5 | 4.2 | 4.5 | 4 | 245*235*180 | 510*258*395 |
| JTPH-A-15 | 9-15 | 1.5 | 4.2 | 4.5 | 4 | 245*235*180 | 510*258*395 |
| JTPH-A-22 | 15-22 | 1.5 | 5.2 | 8.5 | 1 | / | 388*310*232 |
| JTPH-A-30 | 22-30 | 1.5 | 5.2 | 9 | 1 | / | 388*310*232 |
| JTPH-A-40 | 30-40 | 1.5 | 5.2 | 11.5 | 1 | / | 388*310*232 |
| JTPH-A-50 | 40-50 | 1.5 | 5.2 | 12 | 1 | / | 388*310*232 |
| JTPH-A-60 | 50-60 | 1.5 | 5.2 | 12 | 1 | / | 388*310*232 |
| JTPH-A-70 | 60-70 | 1.5 | 5.2 | 13.5 | 1 | / | 388*310*232 |
| JTPH-A-80 | 70-80 | 1.5 | 5.2 | 13.5 | 1 | / | 388*310*232 |
| JTPH-A-100 | 80-100 | 1.5 | 5.2 | 20.5 | 1 | / | 388*310*232 |
| JTPH-A-120 | 100-120 | 1.5 | 5.2 | 21 | 1 | / | 388*310*232 |
| JTPH-A-140 | 120-140 | 1.5 | 5.2 | 21 | 1 | / | 388*310*232 |
| JTPH-A-160 | 140-160 | 1.5 | 5.2 | 22 | 1 | / | 388*310*232 |
| JTPH-A-180 | 160-180 | 1.5 | 5.2 | 24 | 1 | / | 388*310*232 |
| JTPH-A-200 | 180-200 | 1.5 | 5.2 | 26 | 1 | / | 388*310*232 |
