G100 European Type Eye Self-Locking Hook（TH-1005）
Green painted.other colour is available as per request.
Working load limit permanently shown on the body.
Max proof load is 2.5 times of the working load limited.
Min.Breaking strength is 4 times of the W.L.L.
| Size | W.L.L | B.L | Dimension（mm） | Weight | ||||||
| (t) | (t) | Φ | D | E | H | R | M | L | kg/pc | |
| 6-10 | 1.4 | 5.6 | 21 | 43 | 28 | 20 | 110 | 70 | 141 | 0.33 |
| 8-10 | 2.5 | 10 | 27 | 51 | 35.5 | 26 | 137 | 90 | 175 | 0.7 |
| 10-10 | 4 | 16 | 34.5 | 64.5 | 45 | 30 | 169 | 108 | 212.5 | 1.3 |
| 13-10 | 6.7 | 26.8 | 40 | 80 | 53.5 | 40.5 | 209 | 138.5 | 270 | 2.3 |
| 16-10 | 10 | 40 | 50 | 104 | 62 | 50.5 | 254 | 170.5 | 331 | 3.6 |
| 20-10 | 16 | 64 | 60 | 120 | 76.5 | 62 | 277 | 192.5 | 369 | 7.3 |
| 22-10 | 19 | 76 | 70 | 134 | 80 | 66 | 319.5 | 205 | 417 | 12.1 |
