G100 Welded Master Link with Flat（TH-1014）
Green painted.other colour is available as per request.
Working load limit permanently shown on the body.
Max proof load is 2.5 times of the working load limited.
Min.Breaking strength is 4 times of the W.L.L.
| Size | W.L.L | B.L | Dimension（mm） | Weight | ||
| (t) | (t) | A | B | D | kg/pc | |
| 10/8-10 | 4 | 16 | 340 | 180 | 25 | 3.7 |
| 13/10-10 | 6.5 | 26 | 340 | 180 | 28 | 4.7 |
| 16/13-10 | 10 | 40 | 340 | 180 | 34 | 7 |
| 19/16-10 | 14.4 | 57.6 | 340 | 180 | 38 | 8.9 |
